Taper Roller Bearing 32011
video

Taper Roller Bearing 32011

32011 tapered roller bearing, inner diameter 55.000 mm outer diameter 90.000 mm thickness 23.000 mm can be used for oil-free compressors, gantry cranes, classifiers, magnetic separators, steam reciprocating pumps, mine drainage pumps, stamping presses, ships, Hot water submersible pumps are widely used. Tapered roller bearings refer to radial thrust rolling bearings whose rolling elements are tapered rollers. There are two kinds of small cone angles and large cone angles. The slight taper angle mainly bears the combined radial and axial loads primarily based on the radial load. It is often used in pairs and installed in the opposite direction.
Send Inquiry
Product Introduction

32011 tapered roller bearing, inner diameter 55.000 mm outer diameter 90.000 mm thickness 23.000 mm can be used for oil-free compressors, gantry cranes, classifiers, magnetic separators, steam reciprocating pumps, mine drainage pumps, stamping presses, ships, Hot water submersible pumps are widely used. Tapered roller bearings refer to radial thrust rolling bearings whose rolling elements are tapered rollers. There are two kinds of small cone angles and large cone angles. The slight taper angle mainly bears the combined radial and axial loads primarily based on the radial load. It is often used in pairs and installed in the opposite direction. The inner and outer races can be installed separately, and the radial and axial clearances can be adjusted during installation and use; The large cone angle mainly bears the combined axial and radial loads primarily based on the axial load. Generally, it is not used to bear the pure axial load alone, but can be used to bear the pure radial load when it is configured in pairs (the ends with the same name are installed opposite to each other).

 Boundary Dimensions MM  Designation  Load Rating(KN)
 dyn.      stat
 speed ratings(rpm) r1 r2 (min)  mounting dimensions MM Mass (KGS)
da min Da min inner ring  outer ring
d D T B C Cr            Cor ng grease ng oil inner ring  outer ring  ra max
55 90 23 23 17.5 32011 84.6 121 4100 5500 1.5 1.5 63.5 81 1.5 1.5 0.569




Why choose us?

  • We aim to provide a hassle-free and streamlined purchase experience for our customers, from start to finish.
  • We focus on customer needs and ideas, specializing in providing integrated solutions.
  • We are always looking for ways to improve our products and services, to better meet our customers' needs.
  • I did not give you the effort to change the development mode, continue to innovate the business model, service model, control model and incentive model, and constantly stimulate the creative vitality of enterprises.
  • Our focus on continuous improvement and innovation ensures that we remain at the forefront of the Tapered Roller Bearing industry.
  • Our company's strategic goal for the next five years is to attract, train and create a large number of diversified, complex and international high-quality professionals.
  • We are confident in the quality and durability of our Tapered Roller Bearings, which is why we offer a warranty for all of our products.
  • With the development of society, people have higher and higher requirements for the quality of Taper Roller Bearing 32011. We have used strict quality inspection methods for product design, material selection, production, and packaging, so our products can reflect meticulousness, sophistication, and uniqueness. After years of hard work and development and innovation, we have laid a solid foundation and won the trust and trust of our customers.
  • We are a Chinese factory that specializes in high-quality Tapered Roller Bearing products and professional services.
  • Looking forward to the future, we are full of confidence and believe that our sincerity, hard work and professional services will make our cooperation more successful!
