deep groove ball bearing 694

694 bearing is a miniature deep groove ball bearing, with inner diameter 4mm outer diameter 11mm thickness 4mm, model: 694 bearings, can be used for: Cutting MACHINE, drilling sleeve, pressing machine, spray cooling tower, pressure welding machine, iron making equipment, drilling press, waste incinerator, plunger pump, concrete machinery, plastic machine accessories, animal equipment, enamel reaction kettle, non-woven printing equipment, packaging, and so on.

 Deep groove ball bearing installation method, the bearing inner ring and shaft tight fit, outer ring and the bearing hole is a loose fit, press the bearing to be pressed on the shaft is available, and then put the shaft together with the bearing load bearing hole, when pressed on the bearing inner ring end face, cushion the assembling casing made of a soft metal material (copper or mild steel), bearing outer ring and bearing hole tight fit, When the inner ring is loosely matched with the shaft, the bearing can be pressed into the bearing seat hole first, and the outer diameter of the assembly sleeve should be slightly smaller than the diameter of the seat hole. If the bearing ring is tightly matched with the shaft and seat hole, the inner ring and outer ring should be pressed into the shaft and seat hole at the same time. The structure of the assembly sleeve should be able to tighten the end face of the inner ring and outer ring of the bearing at the same time.

 Deep groove ball bearings, bearing load in operation is too small, will cause sliding between the ball and raceway, become the cause of abrasion. In particular, large deep groove ball bearings with a large ball and cage weights have this tendency. In many cases, the bearing rust phenomenon will occur, leading to bearing rust there are many reasons, but the most common in our daily life mainly the following factors:

 1) Due to the poor sealing device, it is invaded by moisture and dirt;

 2) bearings are not used for a long time, beyond the rust prevention period, and lack maintenance.

 3) Large metal surface roughness;

 4) Contact with corrosive chemical media, bearing cleaning is not clean, there is dirt on the surface, or contact the bearing with sweaty hands, bearing cleaning, not timely packaging or installation, long-term exposure to the air, by air moisture invasion and contamination;

 5) Ambient temperature and humidity and contact with various environmental media; Rust inhibitor failure or quality does not meet the requirements.

Why choose us?

• We have the expertise and resources to manufacture Deep Groove Ball Bearings that meet the needs of various customers.
• We believe that our advanced production and R&D technology, excellent management concepts, and perfect after-sales service team will definitely help customers develop a better tomorrow.
• We strive to deliver the highest-quality Deep Groove Ball Bearing products and services to our customers at competitive prices.
• We can customize products according to the actual needs of customers, so as to reduce the production costs of customers as much as possible and increase their interests.
• Our Deep Groove Ball Bearings are designed and manufactured to meet the highest standards of quality and performance.
• We seek new and solid foundations, continue to surpass, and achieve a great leap forward one step at a time every year.
• We aim to build long-term relationships with our customers by providing them with the best Deep Groove Ball Bearings and services.
• We mainly deals in deep groove ball bearing 694, and special specifications products can also be customized according to customer requirements.
• Our factory is equipped with modern technological capabilities to ensure efficient and reliable production of Deep Groove Ball Bearings.
• We are engaged in this deep groove ball bearing 694 industry that has the vitality for long-term sustainable development.
